3/4-16 UNF • Qmax 16 l/min (4 GPM) • pmax 350 bar (5100 PSI)

• Set flow rate independent of load pressure and temperature changes
• Adjusted flow rate depends on the orifice area and adjusted differential pressure
• Hardened precision parts
• High flow capacity
• Quiet and modulated response to load changes
• Used in meter-in, meter-out, or bleed-off applications
• Wide range of flow rate options
• Adjustable by allen key or hand screw, optionally sealable (lockwire holes)
• In the standard version, the valve is zinc-coated for 240 h protection acc. to ISO 9227
