1 1/16-12 UN • Qmax 150 l/min (40 GPM) • pmax 350 bar (5100 PSI)

• Hardened precision parts
• High flow capacity and leak-free closing
• High transmitted hydraulic power up to 350 bar
• Normally open and normally closed version
• Wide range of manual overrides available
• All ports may be fully pressurized
• Coil interchangeability among SD*- C/H* product line
• In the standard version, the valve is zinc-coated (240 h corrosion protection in NSS acc. to ISO 9227)
